Electric Linear Column Actuator

Get a Price/Quote

MOQ : 100 Units

Electric Linear Column Actuator Specification

Motor Type
Permanent Magnet DC Motor

Standard
CE Certified

Pressure
Max 3500 N

Rated Voltage
230 V

Rated Frequency
50 Hz

Cooling Method
Natural Cooling

Starting Type
Direct Start

Features
Low noise, maintenance-free, stable performance

Torque
Max 350 Nm

Ambient Temperature
-10C to +60C

Current Type
AC to DC

Bearing Type
Ball Bearing

Efficacy
High Efficiency

Power Rating
250 W

Horse Power
0.34 HP

Sealed Type
Sealed Housing

Noise Level
< 50 dB

Poles Number
2

Voltage
220-240 V

Product Type
Electric Linear Column Actuator

Output Power
250 W

Frequency (MHz)
50/60 Hz

Protect Feature
Overload Protection

Phase
Single Phase

Speed
5-30 mm/s (customizable)

Power
AC Electric

Color
Gray

Dimension (L*W*H)
100 x 100 x 400 mm (standard stroke, customizable)

Weight
8 kg

Shaft Diameter
25 mm

Mounting Type
Foot Mounted

IP Rating
IP54

Operating Humidity
Up to 85% RH

Operating Position
Vertical

Retracted Length
Minimum 400 mm (custom option available)

Safety Limit Switches
Yes

Cable Length
Up to 2 meters

Duty Cycle
Max 10% at full load

Temperature Protection
Built-in thermal protection

Connector Type
Standard 3-pin or customized

Stroke Length
100 mm, 150 mm, 200 mm, 300 mm, 400 mm, custom

Application
Hospital beds, industrial automation, home lift tables, workstations

Material
Aluminum Alloy Housing, Stainless Steel Shaft

Control Type
Wired Remote or Wireless Remote

Electric Linear Column Actuator Trade Information

Minimum Order Quantity
100 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Electric Linear Column Actuator

Experience the crowning achievement in linear motion technology with our Acclaimed Electric Linear Column Actuator. Crafted with grandiose aluminum alloy housing and a laureate stainless steel shaft, this actuator excels in hospital beds, industrial automation, and home lift tables. Choose from a variety of stroke lengths, custom options, and benefit from competitive pricing during our current promotion. Designed for high efficacy and stability, it ensures safe, quiet, and maintenance-free operation. Its robust sealed construction stands up to rigorous use, making it the premier choice for demanding environments.

Premium Materials & Versatile Applications

With durable aluminum alloy housing and a stainless steel shaft, this Electric Linear Column Actuator excels in both strength and longevity. Its outstanding performance makes it suitable not only for hospital beds but also for workstations, industrial automation, and diverse lifting solutions in home environments. The actuator's robust construction and protective features ensure operational reliability, making it ideal across a variety of demanding application sites.

Speedy Delivery & Competitive Solutions

Enjoy prompt delivery times and sample availability for our Electric Linear Column Actuator. The list price ensures unmatched value for your outlay, catering to both domestic and export markets. Our supply network is spread across India's main domestic market, making procurement seamless and efficient. With a focus on competitive pricing and customer satisfaction, we provide tailored solutions suitable for multiple sectors.

FAQ's of Electric Linear Column Actuator:

Q: How is the Electric Linear Column Actuator controlled?

A: The actuator can be operated using either a wired remote or a wireless remote, depending on your specific installation needs and preferences.

Q: What materials are used in the construction of the actuator?

A: The actuator is built with an aluminum alloy housing and a stainless steel shaft, ensuring durability, resistance to corrosion, and long-term stable performance.

Q: Where can this actuator be applied?

A: Common applications include hospital beds, industrial automation systems, home lift tables, and workstations, but its design allows for use in many lifting and adjustment tasks.

Q: What is the process for obtaining a customized stroke length or cable length?

A: You can request customization at the time of order. Our team will work with you to specify stroke length and cable requirements tailored to your application.

Q: What benefits does the built-in thermal protection provide?

A: The integrated thermal protection safeguards the actuator from overheating, enhancing operational safety and prolonging the service life of the device.

Q: When would maintenance be required for this actuator?

A: Thanks to its maintenance-free design and quality bearings, routine maintenance is seldom needed; however, regular inspections are recommended for demanding industrial setups.
